- Principle:
- Pressure filtration
- Use:
- Solid-liquid separation
- Applicable object:
- sludge
- Style:
- Van type
- Performance:
- High efficiency filtration
- Filter type:
- Non-woven fabric
- Applicable object nature:
- Weak corrosion
- Filtration accuracy:
- 25 um
- Working pressure:
- 0.6 MPa
- Operating temperature:
- 70 ℃
- Effective filtration area:
- 2 ㎡
- Applicable viscosity:
- 15 pas
- Overall dimension:
- 1.3 m
- Equipment weight:
- 565 kg
- Model:
- 390
Yuzhou Xingtai Filtration Equipment Co., Ltd. filter press plate and frame filter diaphragm filter specifications, Xingtai product specifications complete, reasonable design, beautiful shape, exquisite materials, strong durability, strong adaptability. Quality assurance.
Yuzhou City Xingtai Filter Equipment Co., Ltd. series of product characteristics have: 1. good filtration effect;2. high filtration efficiency;3. long service life;4. ideal solid-liquid separation equipment;Xingtai box filter press: the filter plate is a box filter plate, the filter chamber is composed of two adjacent concave box filter plates, the filter cloth is fixed on the filter plate, the feed pump provides pressure, the filter cloth blocks solid materials, and the liquid flows out through the liquid discharge system to complete the purpose of solid-liquid separation;Xingtai plate and frame filter press: the box filter plate and the filter frame are placed at intervals to form a filter chamber, the filter cloth is fixed on the filter plate, the feed pump provides pressure, the filter cloth blocks solid materials, and the liquid flows out through the liquid discharge system to complete the purpose of solid-liquid separation.
Official website: www.yzxingtai. com
basic overview
Name: Filter press
Definition: A mechanical device that uses a special filter medium to exert a certain pressure on the object so that the liquid dialyzes out. Function: To extract solid from mixed liquid and separate solid from liquid. nbsp; ]
Model performance parameters
Filter area (㎡) Filter plate shape size (mm) Filter plate thickness (mm) Filter cake thickness (mm) Filter chamber number (pieces) Filter chamber theoretical volume (L),(m3) Overall shape size (L, W, H)(mm) Installation foundation size (mm) Filter chamber working pressure (MPa) Motor power (KW) Overall weight (KG) Filter plate performance Filter plate structure: plate-frame type, van-type filter plate Filter plate material: stainless steel, cast iron, rubber, reinforced polypropylene (plastic), polymer PE and other properties: acid and alkali resistance, filtration temperature (℃), filtration pressure (MPa)
We are in line with the production excellence, distribution honest and trustworthy, warm and thoughtful service purposes and to assist partners to achieve their careers to achieve their own career spirit, to provide customers with excellent quality and service. Sincerely with the vast number of new and old customers to join hands in creating the future!
If you are interested in purchasing products, please contact our responsible personnel, online or telephone communication:
Please contact our responsible person to ask about the goods to be purchased, inventory and other information, so that you can accurately know the situation of the goods, but also to reduce and avoid unnecessary misunderstanding.
about price
Information prices for my company roughly wholesale prices, friends if you intend to buy a large number, or special circumstances, please contact us, details.
about shipments
We will confirm the cooperation mode and cooperation reached for your delivery. Delivery package we have a strict inspection of the quality of goods, please rest assured that the purchase.
Welcome friends from all walks of life to visit our business department, guidance and business negotiations.- Name（chinese）
- 禹州市兴泰过滤设备有限公司
- Name（English）
- Yuzhou City Xingtai Filtration Equipment Co., Ltd
- China credit code
- 91411081071377868T Identity Verification
- Registered Capital
- 8,500,000 CNY
- Operating term
- 2013-06-19 ~ ****
- Address
-
Henan, China
- Nearby port
- Qingdao,Lianyungang
Yuzhou City Xingtai Filter Equipment Company (Yuzhou City Xingtai Filter Press Manufacturing Factory) is a professional manufacturer of separation equipment. It has a history of producing filter presses for nearly 20 years. Our factory's main products include: series of plate and frame and box filter presses 520, 700, 890, 1000, 1250 and 2000. Filtration area 0.5M2- 500M2. Plate and frame materials include: high-strength polypropylene, glass fiber polypropylene (temperature resistance 120), cast iron and stainless steel plate and frame, etc., which can meet a variety of working environments. The compaction methods include manual compaction, jack compaction, mechanical compaction, hydraulic compaction, automatic pressure maintenance and advanced computer fully automatic programmable control. Filtration forms include open flow, undercurrent, light and dark flow, and two-way cross washing. After continuous exploration and improvement, practice has proved that this series of filter presses are superb and meticulous in workmanship, reasonable and advanced in design, solid and reliable in quality, and easy and efficient to use. The frame of Xingtai series products adopts carbon steel structure, which is strong and durable. The filter plate is made of reinforced polypropylene, which is resistant to high temperature and high pressure, and is not easy to deform and break. It has the characteristics of filter biscuits and pure filtrate, and is suitable for various suspended solid-liquid separation industries. Xingtai products focus on product quality, put reputation first, and serve people with sincerity. Free door-to-door installation and debugging, training technical personnel, and long-term follow-up services. We will sincerely welcome users to come and negotiate business.- Name（chinese）
- 禹州市兴泰过滤设备有限公司
- Name（English）
- Yuzhou City Xingtai Filtration Equipment Co., Ltd
- China credit code
- 91411081071377868T Identity Verification
- Registered Capital
- 8,500,000 CNY
- Operating term
- 2013-06-19 ~ ****
- Address
-
Henan, China
- Nearby port
- Qingdao,Lianyungang
Yuzhou City Xingtai Filter Equipment Company (Yuzhou City Xingtai Filter Press Manufacturing Factory) is a professional manufacturer of separation equipment. It has a history of producing filter presses for nearly 20 years. Our factory's main products include: series of plate and frame and box filter presses 520, 700, 890, 1000, 1250 and 2000. Filtration area 0.5M2- 500M2. Plate and frame materials include: high-strength polypropylene, glass fiber polypropylene (temperature resistance 120), cast iron and stainless steel plate and frame, etc., which can meet a variety of working environments. The compaction methods include manual compaction, jack compaction, mechanical compaction, hydraulic compaction, automatic pressure maintenance and advanced computer fully automatic programmable control. Filtration forms include open flow, undercurrent, light and dark flow, and two-way cross washing. After continuous exploration and improvement, practice has proved that this series of filter presses are superb and meticulous in workmanship, reasonable and advanced in design, solid and reliable in quality, and easy and efficient to use. The frame of Xingtai series products adopts carbon steel structure, which is strong and durable. The filter plate is made of reinforced polypropylene, which is resistant to high temperature and high pressure, and is not easy to deform and break. It has the characteristics of filter biscuits and pure filtrate, and is suitable for various suspended solid-liquid separation industries. Xingtai products focus on product quality, put reputation first, and serve people with sincerity. Free door-to-door installation and debugging, training technical personnel, and long-term follow-up services. We will sincerely welcome users to come and negotiate business. -
